There is one mechanic within storyboarding that will allow you to create some sort of interactive effect with what is happening during gameplay: Triggers. Triggers can catch certain events and execute basic commands on your sprite in response.

Note

Triggers are the most complex command currently provided by the storyboarding API. Unfortunately they are accordingly buggy. This section will cover triggers’ most common oddities and weird behavior, along with a few edge cases towards the end.

Syntax

Like every other command, a trigger is always attached to a sprite or animation.

Triggers consist of merely 4 elements:

  • command-character
  • trigger condition
  • time window
  • trigger group (optional)

After the trigger command you have to list the commands that are to be executed when the trigger condition occurs.

An example of using a simple trigger.
1
2
3
4
5
6
Sprite,Background,Centre,"sb\aoba.png",192.625,140
 F,0,23500,,0
 S,0,23500,,0.2
 T,HitSoundSoft,0,105330
  F,0,0,,1
  F,0,110,,0

T is the character marking the trigger command.

HitSoundSoft is the trigger condition. You will learn about the different kinds of trigger conditions in the next section.

0,105330 marks the start and end time of the trigger. There is no limit to how often a trigger can be executed within the specified timeframe.

The Fade commands after the trigger command are indented by one additional whitespace or underscore to mark them as belonging to the trigger.

It is very important to notice that the time values specified for these commands are relative to the time when the trigger starts executing.

Example: If the trigger condition is met at 23918 the sprite will change to 100% opacity at 23918 and fade out at 24028. This behaviour assures that a trigger can be activated and executed multiple times.

Trigger Conditions

Triggering a trigger is very similar to triggering a trap: It will snap once someone steps into it.

It is not that simple though. Our traps have different tastes and they are picky to different degrees. Let’s check how we can satisfy the taste of each of our traps.

Hitsounds

The first big chunk of possible trigger conditions consists of hitsounds. Every time a note is hit, a hitsound will be played. But Hitsound does not equal Hitsound:

There are as many possible different triggers for hitsounds in a map as hitsounds available.

How do we specify the hitsound we want to have our trap snap on?

This is easy. The naming for the according trigger follows a simple naming scheme as shown in the following table:

Selection of Hitsound Trigger Conditions
Condition Type Sampleset Name Hitsound Addition Sampleset Number Trigger Name
Hitsound Soft Whistle 1 HitsoundSoftWhistle1
Hitsound Drum     HitsoundDrum
Hitsound   Clap   HitsoundClap
Hitsound     4 Hitsound4
Hitsound Normal   2 HitsoundNormal2
Hitsound   Finish 0 HitsoundFinish0

If you’re familiar with hitsounding, then these columns should be very easy to understand. Aside from the prefix “Hitsound” you can individually add or leave out a specification of your hitsound to get the exact hitsound or combination of hitsounds you want.

If you don’t know what any of these mean, consider reading a guide on hitsounding.

Warning

While the naming of the triggers suggests that it checks which hitsound is played, this is actually not the case! Changing the sampleset of a note via the Sampleset Menu on the top left of the editor (Ctrl/Shift+Q/W/E/R) or via Sample Import will be ignored for the sake of evaluating triggers. You always have to change your samplesets via inherited timing sections if you want your Hitsound triggers to work correctly.

Note

You might have noticed that there is no option to catch a hitnormal alone. This is very annoying when you want to catch hitnormals along with other notes that actually have finishers. It can be worked around by changing the sampleset for these notes so you can use Hitsound5 or something like that but it requires a lot of manual effort nonetheless.

If you wonder why this is the case, the answer is that hitnormals work for everyone differently. Currently there is the option to configure the option LayeredHitSounds in your Skin.ini to 0 causing hitnormals no longer be played on notes that have additionals. As this is a setting determined by the user in most cases, there is no way to get a consistent experience for all players without the already mentioned workaround anyway.

Example: Hitsounds

Aoba wants to play the Taiko drum! She is very inexperienced but maybe you can help her out?

Full of optimism: Aoba ...and the Taiko drum!

If you aren’t familiar with Taiko mapping, no problem, we got that covered in a few words.

There are 2 types of notes in Taiko, Don (red) and Kat (blue). If it has a whistle and/or clap hitsound attached it is a Kat, otherwise it is a Don note.

We can make Aoba hit the drum by catching the respective trigger conditions:

Knowing that Kat is characterised by whistle and/or clap we construct the triggers according to the table, resulting in HitsoundWhistle and HitsoundClap.

For Don we have to create a workaround and assign a specific Hitsoundset to each Don note because we can’t react to the hitnormal without reacting to any additional hitsound at the same time.

So let’s say we put Hitsoundset 4 for each Don, meaning we have to specify the trigger condition as Hitsound4.

To make this as simple as possible in terms of example, we’ll introduce 2 more versions of Aoba in which she is using one or the other drumstick to hit the Taiko.

We will also put one of her pigtails into a different sprite so that we can display the drumsticks in front of the drum but her hair behind it. In total we got 5 sprites:

Aoba is idling Aoba is hitting a don Aoba is hitting a kat One of Aoba's pigtails The taiko drum

First of all we are moving our static sprites into place:

Our static sprites
1
2
3
4
5
6
Sprite,Background,Centre,"sb\aobaHair.png",192.625,140
 S,0,0,,0.2
 F,0,0,,1
Sprite,Background,CentreLeft,"sb\drum.png",186,163
 S,0,0,,0.3
 F,0,0,,1

When nothing is happening the idling Aoba sprite should be shown. This will be the case at the start of the beatmap. As soon as any hitsound is played it should get replaced by one of the other two sprites.

Aoba preparing to hit the Taiko
1
2
3
4
5
6
7
Sprite,Background,Centre,"sb\aobaTaikoIdle.png",192.625,140
 F,0,0,,1
 S,0,0,,0.2
 F,0,105330,,0
 T,HitSound,0,105330
  F,0,0,,0
  F,0,110,,1

Fairly simple, isn’t it? Now let’s do the same for the other two sprites except that they are invisible at the start and fade in on the corresponding hitsound.

Aoba hitting the drum with passion!
 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
Sprite,Background,Centre,"sb\aobaTaikoKat.png",192.625,140
 F,0,0,,0
 S,0,0,,0.2
 T,HitSoundWhistle,0,105330
  F,0,0,,1
  F,0,110,,0
 T,HitSoundClap,0,105330
  F,0,0,,1
  F,0,110,,0
Sprite,Background,Centre,"sb\aobaTaikoDon.png",192.625,140
 F,0,0,,0
 S,0,0,,0.2
 T,HitSound4,0,105330
  F,0,0,,1
  F,0,110,,0

And that’s it! Aoba will now play the drum in sync with the map! You can see the application of this effect in the following map: https://osu.ppy.sh/s/597411

Warning

Yes, with the map, not with the player. Hitsound-triggers are only activated by Hitsounds from objects. Otherwise this would be amazing for Taiko-mode effects but you can still do some interesting things with it! The other sad thing is that spinners and drumrolls (except for the head) in Taiko don’t trigger hitsounds but you could perfectly let Aoba drum to an osu!standard difficulty. This solution is far from universal, as you will see in the Pitfalls-section, but it works perfectly fine for Kantans and most Futsuu difficulties.

Change of Game state

Attention

If you are planning to use Passing and Failing triggers in a map for either Catch the Beat or mania, go no further. There is full support for standard and partial support for Taiko (only Don/Kat, no drumrolls/spinners) but none at all for CtB and mania. Keep this in mind before making big plans with this type of trigger.

From reading the chapter about layers and objects you might know already that osu! uses 4 different layers to draw a storyboard. 2 of these layers are Pass and Fail that are displayed in accordance to the current game state. There are 2 trigger conditions corresponding with these layers called Passing and Failing:

  • Passing occurs when the game state is changing from Fail to Pass
  • Failing occurs when the game state is changing from Pass to Fail

Now there is one major hiccup in applying this to storyboards and that is that Pass and Fail-Layers work differently in every game mode.

In osu!standard the game state can only change at the end of a combo. If the last note of the combo gets you a Geki judgement the game state will be Pass, otherwise it will be Fail.

In osu!taiko the game state can change on each note. If the last note was missed, the game state is Fail, otherwise it is Pass. It should also be noted that drumrolls (except for the head? unconfirmed) and spinners don’t count as notes.

In osu!mania and Catch the Beat the game state can only change on breaks. As we learned earlier, triggers always need to correspond to a gameobject. This means that Passing and Failing triggers will have no effect in these gamemodes.

Example: Change of Game state

This example is geared towards osu!standard as it is the only gamemode that has a consistent implementation for these trigger conditions.

It is rather advanced too but it would be boring otherwise, wouldn’t it?

The narrative

Aoba slept in and got the late train! Her only chance to get to work in time is running from the train station to the Eagle Jump office.

But...Aoba is clumsy. If she doesn’t take care she will trip time and time again and not make it. It is up to the player to support Aoba in running.

The plan

On the Background layer we will put a picture of a street that is sidescrolling.

In Pass-state there will be an animation of Aoba running.

In Fail-state Aoba will lie on the ground after having tripped.

On triggering Failing, Aoba will be tripping.

On triggering Passing, Aoba will get up from the ground.

The implementation

For the sidescrolling street we will take it easy as a start. After a quick google search a 2.5D animation of scrolling buildings turns up.

Splitting that into frames, renaming the individual pictures to use as an animation (I used a script for this because it has about 250 files) and we’re ready to go.

Scrolling buildings

Now all we have to do is creating an animation with our existing knowledge:

Buildings passing along...
1
2
3
4
Animation,Background,Centre,"sb\streetscroll\streetscroll.png",320,140,240,150,LoopForever
 F,0,0,,1
 S,0,0,,2
 F,0,90000,,0

And the street is running. Now to the more exciting stuff...

I prepared some animations to use for running, tripping and getting up (actually the hardest part).

Running character Falling character Character getting up.

Let’s start by putting the Pass-layer into place. While the gamestate is Pass the running-animation is displayed.

Character running in Pass-state
1
2
Animation,Background,Centre,"sb\running\running.png",320,240,240,150,LoopForever
 F,0,0,,1

Simple as that. We have to make another addition for the case that the Passing event is triggered.

When this happens, Aoba is supposed to get up first before she starts running again. This means we have to fade the animation out for the process of getting up.

Character running in Pass-state with transition
1
2
3
4
5
Animation,Pass,Centre,"sb\running\running.png",320,240,6,150,LoopForever
 F,0,0,,1
 T,Passing,0,90000
  F,0,0,,0
  F,0,1000,,1

The value of 1000 is arbitrary, it has to be set to the actual duration of getting up.

Now the same is done for the Fail-layer with the Failing trigger. This time it is a sprite, not an animation as Aoba is just lying down.

Character lying on the ground
1
2
3
4
5
Sprite,Fail,Centre,"sb\falling\fallen.png",280,240
 F,0,0,,1
 T,Failing,0,90000
  F,0,0,,0
  F,0,2000,,1

As the last step put in the animations for falling and getting up.

Character falling
1
2
3
4
Animation,Fail,Centre,"sb\falling\falling.png",280,240,9,150,LoopOnce
 T,Failing,0,90000
  F,0,0,,1
  F,0,1000,,0
Character getting up
1
2
3
4
Animation,Pass,Centre,"sb\gettingup\gettingup.png",320,240,8,150,LoopOnce
 T,Passing,0,90000
  F,0,0,,1
  F,0,2000,,0

Oh hey, that is easy, isn’t it?

Yes, too easy to actually work. Otherwise this would be the coolest interactive storyboard in 29 lines ever.

The problem with using animations here is that they run independently from the trigger:

  • When using LoopOnce as the loop-option they will work fine on the first trigger but show only the last animation frame on consecutive triggers.
  • When using LoopForever the animation will work fine on the first trigger but start and end on the wrong frame for consecutive ones.

The slightly annoying but in this case bearable workaround is animating by hand. This means creating a sprite for every frame of the animation and fading it in and out with the proper delay according to its position within the animation. If you understood how an animation works, this should be trivial to do. Refer to the tutorial on animation if you have trouble.

Warning

So we learned that you can’t use triggers on animations if they are supposed to be displayed more than once. For recreating the animation with triggers on its individual sprites you have to explicitly fade them out at the start of the trigger as they will otherwise fade in as soon as the trigger starts executing.

Note

It should be noted that all combos in the map you’re storyboarding for have to be at least as long as the longest transition effect (in this case 2 seconds of getting up). Otherwise the effects will overlap or not flow well into each other (assuming you counteracted the overlapping issue) and make it look very bad. 2 seconds for a combo in osu! standard is very reasonable though so this would work in most beatmaps.

Todo

Add an example .osz file of a map that utilises this effect.

Trigger Groups

Todo

Mechanic explanation, use-case: workaround for triggering on negations (player missed a note), hopefully a cool example that takes advantage of the very specifics of the mechanic!

Pitfalls

Interaction with commands outside of the trigger

Todo

Command Locking, Fade Behaviour

Interaction with other triggers

Todo

This might go into the Trigger Groups part in detail because it is most relevant there. A quick summary would make sense though.

Supported hitobjects

Todo

Write a small summarising list to give an overview on which gameobjects triggers are working and maybe more importantly on which ones not.
